Cable part numberCable part number ColorColor FromFrom ToTo
756914-001 Orange Optical drive Optical drive SATA-power
connector
Option kit: P56608-B21
GPU auxiliary power cablingGPU auxiliary power cabling
The exact route of the GPU auxiliary power cabling will depend on the:
The riser cage where the accelerator is installed.
The location of the power connector on the accelerator.
Use the following diagrams for reference only.
1
1
