HPE ProLiant ML350 Gen11

To Next Page

To Previous Page

Option kit: P47232-B21

8 SFF drive: Onboard NVMe cabling8 SFF drive: Onboard NVMe cabling

Cable part numberCable part number ColorColor FromFrom ToTo

P45294-001 Orange Box 3 ports 1–4 x8 SlimSAS ports 1A-4A

Option kit: P48399-B21

12 12 E3.SE3.S drive: Onboard NVMe cabling drive: Onboard NVMe cabling

HPE ProLiant ML350 Gen11 Server Maintenance and Service Guide 215
