Do not save the recovery key/password on an encrypted drive.

HPE NS204i-u Boot Device HPE NS204i-u Boot Device componentscomponents

ItemItem DescriptionDescription

1 Boot device cage

2 M.2 slots

3 Boot device

carriers

HPE NS204i-u Boot Device HPE NS204i-u Boot Device LED definitionsLED definitions

HPE ProLiant ML350 Gen11 Server Maintenance and Service Guide 208
