HPE ProLiant ML350 Gen11

9. Remove the E3.S drive cage:
a. Remove the drive cage screws (callout 1).
b. Remove the E3.S drive cage from the server (callout 2).
10. Remove the E3.S drive backplane:
a. Remove the backplane screws (callout 1).
b. Remove the backplane from the drive cage (callout 2).
ResultsResults
To replace the component, reverse the removal procedure.
