ItemItem DescriptionDescription
1 PCIe5 x16 (8, 4, 1) slots
2 RDX power connector
3 PCIe SlimSAS port 2
4 PCIe SlimSAS port 4
5 PCIe SlimSAS port 3
6 PCIe SlimSAS port 1
Not for use in this server.
Riser slot numberingRiser slot numbering
Primary and secondary riser slots are PCIe5 x16 (16, 8, 4, 1) or PCIe5 x16 (8, 4, 1) .
Tertiary riser slots are PCIe5 x16 (8, 4, 1).
All riser slots are rated for a maximum power draw of 75 W each without an auxiliary power cable.
