HPE ProLiant ML350 Gen11

To Next Page

To Previous Page

CAUTION:CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with

either a component or a blank.

ProcedureProcedure

1. Open the front bezel .

2. Remove the drive blank.

LFF drive blank

SFF drive blank

E3.S drive blank

HPE ProLiant ML350 Gen11 Server Maintenance and Service Guide 55
