4. Address Mapping
The function parameters and status parameters are all mapped as Modbus’s read-write register.
Parameter Address Mapping
Their group numbers are mapped as higher bytes of register address while the relationships are shown
as below table.
The index in the group is mapped to the low byte of the register address, the index of parameters F00 -
F20 refer to the user manual.
High Bytes of
Register Address
Group
Number
High Bytes of
Register Address
Group
Number
High Bytes of
Register Address
Group
Number
0x00 F00 0x07 F07 0x0e F14
0x01 F01 0x08 F08 0x0f F15
0x02 F02 0x09 F09 0x10 F16
0x03 F03 0x0a F10 0x11 F17
0x04 F04 0x0b F11 0x12 F18
0x05 F05 0x0c F12 0x13 F19
0x06 F06 0x0d F13 0x14 F20
Status Parameter (0x33) Address Mapping
The status parameters (0x33) are mapped as higher bytes of the register address, and the intergroup
indexes are as following:
Address Function Address Group No.
0x3300 Controller series 0x3315 DC bus voltage
0x3301 Software version of DSP 0x3318 AI voltage
0x3302 Special software version of DSP 0x3319 AI voltage (after calculating)
0x3303 Software version of keypad 0x3322 Heatsink temperature
0x3304 Elevator running status 0x3323 Input terminal status
0x3305 Rated current of HD5L-PLUS 0x3324 Output terminal status
0x3306 Controller status 0x3325 Modbus status
0x3307 Control mode 0x3326 Total time at power-on (hour)
0x3308 Setting speed 0x3327 Total running time (hour)
0x3309 Setting speed (after Acc./Dec.) 0x3328 Run times
0x330A Feedback speed 0x3329 Present fault
0x330B Setting frequency 0x332A SINCOS encoder C phase AD sampling value
0x330C Setting frequency (after Acc./Dec.) 0x332B SINCOS encoder D phase AD sampling value
0x330D Output frequency 0x332C SINCOS encoder A phase AD sampling value
0x330E Setting Rpm 0x332D SINCOS encoder B phase AD sampling value
0x330F Running Rpm 0x332E UVW status of UVW encoder
0x3311 Output voltage 0x332F Electrical angle
0x3312 Output current 0x3332 Pulses of PG
0x3313 Output torque 0x3336 Start rolling pulse monitoring
0x3314 Output power 0x3337 Start the stability judgment source
