Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD5L-PLUS Series User Manual V1.0 63
6.2.13 F12: Digital I/O Terminal Parameters
Ref. Code
Function Description Setting Range [Default]
Input terminal filter time
Defines filter time of DI terminal and to set input terminal sensibility.
• If the DI terminal is easily disturbed and causes malfunction, F12.00 can be increased, but the sensitivity
of the terminal will be reduced.
F12.02 DI2 function 000 - 134 [2]
F12.04 DI4 function 000 - 134 [4]
F12.06 DI6 function 000 - 134 [6]
F12.08 DI8 function 000 - 134 [0]
F12.10 DI10 function 000 - 134 [0]
Note: Hundred digit = 0, normally open input selected; Hundred digit = 1, normally closed input selected.
0: Unused.
• Does not operate even if there is a signal input.
• The unused terminal is recommended to be set as 0 so as to avoid wrong connection or action.
1: Controller enabled (EN).
• When enabled, HD5L-PLUS is enabled to run.
• When diasbled, the running operation is prohibited in the stop state, and the running state is coast to
stop.
• When no terminal selects this function, default controller enabled.
2, 3: UP/DN.
• Set control terminal to control up and down of elevator, see the table below.
UP Terminal (No. 2) DN Terminal (No. 3) Elevator Status
0 0 Stop
0 1 Down
1 0 Up
1 1 Stop
4 - 6: MS1 - MS3.
• Achieve 8-speed running curve via terminals logic combination, see the table below.
MS3 Terminal
(No. 6)
MS2 Terminal
(No. 5)
MS1 Terminal
(No. 4)
Multi-speed Setting
0 0 0 Multi-speed 0 (F05.00)
0 0 1 Multi-speed 1 (F05.01)
0 1 0 Multi-speed 2 (F05.02)
0 1 1 Multi-speed 3 (F05.03)
1 0 0 Multi-speed 4 (F05.04)
1 0 1 Multi-speed 5 (F05.05)
1 1 0 Multi-speed 6 (F05.06)
1 1 1 Multi-speed 7 (F05.07)
To Next Page
