hpmont HD5L-PLUS Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
64 HD5L-PLUS Series User Manual V1.0
Ref. Code Function Description Setting Range [Default]
7: Inspection input (INS).
• If enabled, elevator performs inspection running.
• Control the elevator inspection up or down together with up/down (DN) (No. 2 and 3 function).
8: Emergency running input (BAT).
• If enabled, elevator will enter emergency running status.
9: Contactor feedback input (CSM).
10: Brake feedback input (BSM).
11 - 14: Weighing input 1 - 4 (WD1 - WD4).
• Input the weighing signal of the switching value through this terminal, the controller outputs the
corresponding bias torque according to the signal, and controls the elevator to start smoothly
• Select WD1-WD4 according to the actual number of weighing switches used, and set the
corresponding load weight of each switch with F06.08 - F06.11 (DI weighing signal).
• If multiple terminals are enabled, the max No. terminal will be enabled.
For example: If WD1 and WD2 are valid at the same time, only WD2 is valid
15: Motor overheat input (OH).
16: Fault reset input (RST).
• When HD5L-PLUS alarms fault, reset it by this terminal.
• The function of RST terminal is the same as the STOP key.
17: Up forced speed input (UPF).
18: Down forced speed input (DNF).
19: Governor feedback input (OSG).
20 - 33: Unused.
34: External fault (EXT).
• Input the fault signal of external equipment through this terminal, the controller can monitor the fault
of external equipment. After the controller receives the EXT signal, it will report E24 (external
equipment fault).
F12.13 Filter time of multi-speed terminal 0.000 - 2.000 [0.010s]
Defines the MS filter time to make up for the time error of MS input terminals.
• F12.13 can be modified according to the degree of asynchrony between multiple multi-speed input
terminals.
F12.15
DO1 function
0 - 21 [2]
F12.16
DO2 function
0 - 21 [3]
F12.17
Y1 function
0 - 21 [0]
F12.18
Y2 unction
0 - 21 [0]
F12.19
Y3 function
0 - 21 [0]
F12.20
Y4 (R LY ) function
0 - 21 [0]
0: Unused. No any other actions.
1: Controller is ready.
• ON signal will output if HD5L-PLUS has no fault.
2: Controller is in running.
• HD5L-PLUS is in running status and outputs indicating signal.
3: Zero-speed running.
• ON signal will output if output speed of HD5L-PLUS is zero but HD5L-PLUS is in run status.
4: Zero-speed.
• ON signal will output if output speed of HD5L-PLUS is zero.
