Ref. Code Function Description Setting Range [Default]
F14.44
SINCOS encoder phase B amplitude
0 - 65535 [0]
When F14.39 Bit8 = 1, F14.41 - F14.44 are automatically learned during auto-tuning of synchronous motor.
After completion, optimize the analog AB signal of the SINCOS encoder.
6.2.16 F15: Display Control Parameters
Ref. Code Function Description Setting Range [Default]
F15.00
Language selection
0 - 9 [0]
Defines the language displayed on the LCD keypad. An optional LCD eypad is required.
0: Chinese.
1: English.
2 - 9: Unused.
F15.01
Display contrast of LCD keypad
1 - 10 [6]
Select LCD display contrast. An optional LCD keypad is required.
F15.02
Set parameter 1 of run status
0 - 32 [5]
F15.03 Set parameter 2 of run status 0 - 32 [6]
F15.04
Set parameter 3 of run status
0 - 32 [10]
F15.05
Set parameter 4 of run status
0 - 32 [11]
F15.06
Set parameter 5 of run status
0 - 32 [0]
F15.07
Set parameter 6 of run status
0 - 32 [0]
F15.08
Set parameter 1 of stop status
0 - 32 [4]
F15.09 Set parameter 2 of stop status 0 - 32 [14]
F15.10
Set parameter 3 of stop status
0 - 32 [16]
F15.11
Set parameter 4 of stop status
0 - 32 [26]
F15.12
Set parameter 5 of stop status
0 - 32 [27]
F15.13
Set parameter 6 of stop status
0 - 32 [0]
The keypad displays parameters which is the run status (F15.02 - F15.07) or stop status (F15.08 - F15.13).
• It can be cycling displayed by key on the keypad.
• For instance: When set F15.08 as 7, the stop parameter is setting Rpm at initial power on.
0: Unused.
1: Rated current of HD5L-PLUS.
2: Controller status.
• Refer to D00.06.
3: Operate channel.
4: Setting speed.
5: Setting speed (after Acc./Dec.)
6: Output frequency.
7: Setting Rpm.
8: Actual Rpm.
9: Unused.
10: Output voltage.
11: Output current.
12: Output torque.
13: Output power.
14: DC bus voltage.
15: AI input voltage.
16: AI input voltage (after calculating).
17 - 24: Unused.
25: Heatsink temperature.
26: Input terminal status.
• Bit0 - Bit9 correspond to DI1 - DI10.
27: Output terminal status.
• Bit0 - Bit5 correspond to DO1, DO2, Y1 - Y3, Y4
(RLY ).
28: Modbus status.
29: Total time at power on (hour).
30: Total running time (hour).
31, 32: Unused.
