hpmont HD5L-PLUS Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
48 HD5L-PLUS Series User Manual V1.0
6.2 Group F: General Function Parameters
6.2.1 F00: Basic Parameters
Ref. Code Function Description Setting Range [Default]
F00.00
Motor type
0,1 [0]
0: Asyn. motor.
1: Syn. motor.
F00.01
Control mode
0 - 6 [2]
0: V/f control. Constant voltage/frequency ratio control.
• It is applicable for special elevator occasion. This mode does not need the encoder and the control
effect is not so good as the vector control.
• When select V/f control, properly set the V/f control parameter (F07) to achieve proper efficiency.
1: SVC control. Sensorless vector control. It is only applicable for Asyn. motor.
2: VC control. Sensor vector control.
• Closed-loop vector and applicable for high accuracy speed control occasion. Generally the elevator
will take this mode.
3: Unused.
4: SVC4 control.
5: SVC5 control.
6: SVC6 control.
Note:
1. V/f control are temporary running modes applicable when the motor does not install encoder and the
elevator is in inspection running.
2. SVC control is only available for Asyn. motor.
3. Set motor parameter auto-tuning when select SVC or VC control.
Auto-tuning steps: Correctly set the motor nameplate parameters (F07.00 - F07.04/F10.00 - F10.05), then
start the motor parameter auto-tuning to obtain the right parameters. Meanwhile set vector control
parameters of group F08 to achieve vector control efficiency.
F00.02
Rated speed of elevator
0.100 - 4.000 [1.500m/s]
Refers to nominal rated speed of elevator.
• All speed setting value must < F00.02.
F00.03
The Max. output frequency of HD5L-PLUS
5.00 - 100.00 [50.00Hz]
Defines the Max. frequency that HD5L-PLUS is allowed to output.
• Be careful to set reasonable parameters according to the nameplate of the motor and the actual
operating conditions.
F00.04
Mechanical parameters of motor
10.0 - 6000.0 [60.0]
Defines the relationship between the elevator speed and the motor rotary speed.
• Calculated according to the parameters of the motor, to determine the accuracy of the control, F00.04
must be set correctly.
Elevator speed
(
m s
⁄ )
=
Rotary speed of motor
(
rpm
)
60
×
F00.04
1000
The formula for calculating F00.04 is:
F00.04 =
π × D
i × Winding mode
• D: Diameter of motor (mm); i: Dec. rate; Winding mode: The way that the hoist cable is wound, set
according to the actual elevator setting.
