Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Electrical Installation
HD5L-PLUS Series User Manual V1.0 19
4.4.2 Control Terminal
Figure 4-3 Control terminal
J1
CN13
CN12
USB
P24V
DI10
DI1 DI2 DI3 DI4 DI5 DO1 COM
DI6 DI8 DI9 DO2
COM
DI7 /
/ Y1 CM1 CM2Y2
CM3 RC
Y3 RA RB
MOD+
MOD-
GND
+10V
AI
GND
4
