hpmont HD5L-PLUS Series User Manual

Chapter 3 Mechanical Installation Shenzhen Hpmont Technology Co., Ltd.
12 HD5L-PLUS Series User Manual V1.0
3.3 Installation Direction and Space
To achieve good cooling efficiency, the HD5L-PLUS must
be installed vertically.
There must be enough space betweem
adjacent objects or
baffles (such as walls). The installation space dimensions
are shown in
Figure 3-1, the unit is mm.
Figure 3-1 HD5L-PLUS installation
3.4 Dimensions and Weight
The dimensions and weight of HD5L-PLUS are as shown in Table 3-1. For the corresponding model of
the installation dimension, please refer to section 2.3 Rated Value, on page 6.
Size F3 - F4
Size F5 - F6
Figure 3-2 Size
≥50
≥50
≥30 ≥30
W1
W
H
H1
4-Ød
D
4-Ød
W
W1
H
H1
D
H2
