hpmont HD5L-PLUS Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
50 HD5L-PLUS Series User Manual V1.0
6.2.2 F01: Protection of Parameters
Ref. Code Function Description Setting Range [Default]
F01.00
User’s password
00000 - 65535 [00000]
XXXXX: To enable the password protection function, set any non-zero number as the password.
• Once the password is set, and detect that there is no press on the keypad within 5 minutes, the user’s
password will take effect.
• To change the parameters, input correct password, otherwise can only view it.
00000: Indicates that there is no user password.
• If user unlocks the password, it means clearing the user’s password.
F01.01
Menu mode
0,1 [0]
0: Full menu mode.
• All parameters can be displayed.
1: Checking menu mode.
• Only parameters different from factory setting can be displayed.
F01.02
Function code parameter initialization
0 - 3 [0]
0: No operation.
• HD5L-PLUS is in regular parameter read and write status.
• Whether can change the parameter depends on the user’s password status and the actual operating
conditions of HD5L-PLUS.
1: Restore to factory settings.
• Except group F01, F07.00 - F07.14, group F10, group F11, F15.00, F17.11 - F17.27, group F18 an d Y.
• Steps: Set F01.02 = 1, press , the keypad will display "dnLd", and the stop state parameters will
be displayed after completion.
2: Download the keypad EEPROM parameter to the current function code.
• Except group F01, F17.11 - F17.27, group F18 and Y.
• Motor parameters, encoder parameters and magnetic pole angle etc. will be downloaded.
Record the original parameters such as motor parameters, encoder parameters and magnetic pole
angle etc. Or restart parameter auto-tuning.
3: Clear fault information.
• The fault history of F17.11 - F17.27 will be cleared.
F01.03
Keypad EEPROM parameter initialization
0,1 [0]
0: No operation.
• HD5L-PLUS is in regular parameter read and write status.
1: Upload the current function code settings to the keypad EEPROM parameter.
•
Group F01, F17.11 - F17.27, group F18 and Y do not upload.
