Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information
HD5L-PLUS Series User Manual V1.0 7
2.4 Technical Data
Electrical
Input voltage
Single/three phase: 200 - 240V
Three phase: 200 - 240V
Three phase: 380 - 460V
Fluctuating within ±10%, unbalance rate <3%
Input frequency 50/60Hz ± 5%
Output voltage 0V - input voltage
Output frequency 0.00 - 100.00Hz
Performance
Maximum current
150% rated output current for 2 minutes
180% rated output current for 10 seconds
Control mode V/f, SVC, VC
Running command Keypad; Terminal; SCI communication
Speed setting Digital; Analog; SCI communication
Speed resulotion
Digital setting: 0.01Hz
Analog setting: 0.1% × max-frequency
Speed control accuracy SVC: ±0.5% VC: ±0.05%
Speed control range SVC: 1:100 VC: 1:1000
Torque control response SVC: <200ms VC: <50ms
Start torque SVC: 180% rated torque/0.5Hz VC: 180% rated torque/0Hz
Torque control accuracy ±5%
Characteristic Functions
Parameter upload and
download function
Achieve 2 groups parameters uploading and downloading
• From the control board to the keypad
From the keypad to the control board
Programmable input and
output terminals
Edited input/output terminal functions
Modbus communication Standard Modbus communication protocol
Protection Functions
Auto-inspection
To eliminate the potential safety problems, safety inspection for the peripheral devices
is provided when power on
Over-speed protection To make sure safe running, elevator over-speed protection is provided
Speed deviation
protection
To eliminate the potential safety problems, speed deviation detection protection is
provided
Up or Down forced speed
switch function
Up or Down forced speed switch function, to avoid climbing elevator or plunging
elevator
Input or Output phase loss
protection
Input or Output phase loss auto-detect and alarm function
Motor temperature
detection
Real time detection for the motor temperature
Output GND short circuit
protection
Enabled
