hpmont HD5L-PLUS Series User Manual

Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd.
8 HD5L-PLUS Series User Manual V1.0
Protection Functions
Output inter-phase short
circuit protection
Enabled
Input and Output
Analog power supply +10V, the Max. output current is 100mA
Digital supply +24V, the Max. output current is 200mA
Analog input AI: Voltage 0 - 10V
Digital input DI1 – DI10: Voltage 0 - 30VDC
Digital output DO1, DO2: Voltage 0 - 30VDC, the Max. output current is 50mA
Relay output
Y1: Contact rating 250VAC/5A or 30VDC/5A
Y2, Y3: Contact rating 250VAC/3A or 30VDC/1A
RA, RB, RC: Contact rating 250VAC/5A or 30VDC/5A
Communication
RJ45 interface
MOD+, MOD-: 485 communication
USB Connect the bluetooth module (MT70-BLE-A), use the mobile phone for debugging
Keypad
LED display
5 digit LED digital tube, 5 unit indicator lights, 5 status indicator lights
• Setting function parameter, checking status parameter, checking fault code etc.
• Achieve quick parameter copy
Environment
Running temperature
-10 - +40°C, the Max. is 50°C, air temperature fluctuation is less than 0.5°C/min
The derating value of output current of HD5L-PLUS shall be 2% for each degree
centigrade above 40°C.
Storage temperature -40 - +70°C
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive, flammable gases, oil mist,
water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Vibration resistance 3.5m/s
2
in 2 - 9Hz, it is 10m/s
2
in 9 - 200Hz (IEC 60721-3-3)
Protection class IP20
Pollution level Level 2 (dry, non canducting dust pollution)
Remote update
Remote update Firmware remote update system download kit (HD-OTA-A)
Mobile phone debug Bluetooth module (MT70-BLE-A)
PG card
Serial communication PG card with FD output (HD5L-PLUS-PG1-SC) (support Endat)
OC PG card with FD output (HD-PG2-OC-FD-A)
SINCOS PG card with FD output (HD-PG5-SINCOS-FD-A)
Long-line drive PG card with FD output (HD-PG6-UVW-FD)
About keypad LED keypad (HD-LED)
Power unit Power regenerative unit [HDRU]
