hpmont HD5L-PLUS Series User Manual

Chapter 5 Operation Instructions Shenzhen Hpmont Technology Co., Ltd.
36 HD5L-PLUS Series User Manual V1.0
5.1.2 Controller Status
Controller Status Description
Stop status
After HD5L-PLUS is switched on and initialized, if no run command inputs or the stop
command is given, there will be no output from U/V/W of HD5L-PLUS and the FWD or REV
indicator of the keypad flashes.
Run status
The controller will start output from U/V/W terminals after it receives the run command.
And the FWD or REV indicator of the keypad is always on.
Motor parameters
auto-tuning
Set F07.06/F10.10 = 1 or 2, HD5L-PLUS will enter motor parameters auto-tuning status. If
the process is completed, the controller will enter into stop status.
Fault alarm status HD5L-PLUS has fault.
Under-voltage status HD5L-PLUS is under-voltage.
5.1.3 Control Mode
HD5L-PLUS series have four control modes: V/f control, SVC control, VC control and SVC5 control,
F00.01 setting.
5.1.4 Controller Running Mode
Running Mode Description
Auto-tuning running Set F07.06/F10.10 = 1 or 2, press RUN key to enter the auto-tuning running.
MS speed running
The run speed is set by MS1 - MS3 in combination or communication.
•
F00.05 = 2 or 4.
Inspection running
When inspection signal is valid, the speed will be set by F05.08 (inspection run speed).
• F00.05 = 1, 2 or 4.
Emergency running
When emergency signal is valid, the speed will be set by F05.09 (emergency running speed).
•
F00.05 = 1, 2 or 4.
Normal running Controlled by keypad (F00.05 = 0) or terminal analog (F00.05 = 1).
