Ref. Code Function Description Setting Range [Default]
F19.89
SVC6 I/F control frequency cutoff point
2.00 - 10.00 [4.00Hz]
F19.90 SVC6 I/F control torque given 0 – 200 [100Hz]
F19.91
Maintenance password
0 – 65535 [53214]
F19.92 Maintenance function activation option 0,1 [0]
0: Not activated.
1: Activating the maintenance function and shutting down due to failure.
F19.93
Maintenance method
0 – 2 [0]
0: Invalid.
1: According to the number of runs.
2: According to the power-on time.
F19.94
Maintenance times
0 – 65535 [20000]
F19.95
Maintenance set power-on time
0 – 2700 [90 days]
F19.96
SVC6 IF control transition optimization
0,1 [1]
F19.98
SVC5 start processing
0,1 [1]
0: Normal processing.
1: Optimized processing.
6.2.21 F20: Enhance Parameter Group 2
Ref. Code Function Description Setting Range [Default]
F20.00 Start DC braking current 50 - 150 [100%]
F20.01
Start DC braking current keeping time
0.0 - 3.0 [0.0s]
F20.20/F20.21 is valid only when F00.01 ≠ 2 (VC control).
When F20.01 = 0, the DC braking function is disabled.
F20.02
DI enable function
0,1 [0]
0: Original plan.
• There is an enable signal to output the running contactor.
1: New plan.
• There is a running command signal to open the running contactor. When the open contactor signal is
received, if the enable signal is detected, it can continue to run.
• Used controller controls the running contactor and uses the contactor feedback contact as an enable
signal.
F20.03
Output contactor opening time
0 - 9 [0s]
0: Always on..
1 - 9: With direction signal, and contactor open time > F20.03, after the enable signal is still invalid, close the
output contactor.
F20.04
Output ground detection before operation
0,1 [0]
F20.05 Encoder C, D disconnection detection 0,1 [0]
0: Detect.
1: Not detected.
F20.06 Speed control proportional gain 1 0 - 100 [30]
F20.07
Speed control integration time 1
0.01 - 10.00 [0.50s]
F20.08 Speed control proportional gain 2 0 - 100 [20]
F20.09
Speed control integration time 2
0.01 - 10.00 [1.00s]
6
