6.2.12 F11: Encoder Parameters
In elevator application, the PG is necessary for the motor. Please refer to section 4.5 for PG card.
Ref. Code Function Description Setting Range [Default]
F11.00
PG card selection
1 - 4 [1]
1: HD-PG2-OC-FD-A, the OC PG card with frequency division output.
• Only for Asyn. motor.
2: HD-PG6-UVW-FD, the long-line driver PG card with frequency division output.
• Only for Syn. motor.
3: HD-PG5-SINCOS-FD-A, the SINCOS PG card with frequency division output.
• Only for Syn. motor.
4: Unused.
F11.01
Encoder pulses per revolution
1 - 9999 [2048]
F11.02
Emergency encoder rotation direction setting operation
0,1 [0]
Defines whether the direction represented by the wiring sequence of the controller and the motor is
consistent with the direction represented by the wiring sequence of the PG card.
• Change F11.02 is equivalent to changing the encoder AB two-phase phase sequence
0: The same direction.
1: The reverse direction.
F11.03 Encoder signal filter coefficient 0x00 - 0x77 [0x11]
Unit: Low-speed filter coefficient.
Ten: High-speed filter coefficient.
F11.04
Serial communication encoder protocol
0 - 9 [0]
0: Endat.
1: Rotary transformer protocol.
2 - 9: Unused.
F11.05
Encoder disconnection detection time
0.00 - 2.00 [1.00s]
When the controller detects that the encoder is disconnected, and the duration > F11.05, the controller
reports E31 (encoder disconnection).
• When F11.05 = 0, the HD5L-PLUS does not detect encoder disconnection.
