hpmont HD5L-PLUS Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
70 HD5L-PLUS Series User Manual V1.0
Ref. Code Function Description Setting Range [Default]
F16.13
UPS running direction auto-determine enable
0 - 4 [0]
0: Not enable.
1: The current judges the running direction.
2: The encoder direction judges the running direction.
3: The current judges the running direction (without start compensation and zero speed hold).
4: The encoder direction judges the running direction (without start compensation and zero-speed hold).
Note: Method 2 and 4 must select closed loop vector control (F00.01 = 2) and HD5L-PLUS control elevator brake
output.
F16.14
Running minimum current limit
0 - 100 (F07.11) [20%]
F16.15 Running minimum detect time 0.0 - 5.0 [0.0s]
When the elevator run current < F16.14 and duration > F16.05, HD5L-PLUS will alarm E25 fault (too small
running current).
F16.16
Governor fault detection time
0.0 - 2.0 [1.0s]
When the detection terminal of governor detects signal and duration > F16.16, HD5L-PLUS alarms E37 fault
(governor fault).
F16.17
DC braking current at stop
0 - 150 [100%]
F16.18
Starting frequency of DC braking current at stop
0.20 - 10.00 [0.50Hz]
F16.19
Brake release frequency
0.00 - 10.00 [0.00Hz]
6.2.18 F17: Fault Protect Parameters
Motor
Overheat Fault (F17.00, F17.01)
Ref. Code Function Description Setting Range [Default]
F17.00
Input voltage at motor overheat
0.00 - 10.00 [0.00V]
F17.01 Motor overheat analog signal input type 0 - 2 [0]
0: Not detect the motor overheat.
1: Positive charateristic (PTC).
2: Negative charateristic (NTC).
Input and
Output Phase Loss Fault (F17.03 - F17.06)
Ref. Code Function Description Setting Range [Default]
F17.03
The detection base of lack of input
0 - 100 [30%]
F17.04
The detection time of lack of input
0.0 - 5.0 [1.0s]
F17.03 is a percentage of rated voltage of HD5L-PLUS.
When HD5L-PLUS detects a phase input voltage < F17 03 and the holding time > F17.04, it alarms E15 fault
(input voltage phase loss).
•
F17.03 or F17.04 = 0 or in emergency operation mode, HD5L-PLUS will not detect input phase loss fault.
F17.05
The detection base of lack of output
0 - 100 [20%]
F17.06
The detection time of lack of output
0.0 - 20.0 [3.0s]
F17.05 is a percentage relative to the rated current of HD5L-PLUS.
When HD5L-PLUS detects a phase output current < F17.05 and the holding time > F17.06, it alarms E16
fault (output voltage phase loss).
• F17.05 or F17.06 = 0, HD5L-PLUS will not detect output phase loss fault.
