hpmont HD5L-PLUS Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
72 HD5L-PLUS Series User Manual V1.0
Fault
History (F17.11 - F17.27)
Ref. Code Function Description Setting Range [Default]
F17.11
Five times (at the recent) fault type
[Actual]
F17.12
Setting freqency at the recent fault
F17.13 Output freqency at NO.5 fault
F17.14 DC bus vlotage at NO.5 fault
F17.15
Output voltage at NO.5 fault
F17.16
Output current at NO.5 fault
F17.17
Input terminal status at NO.5 fault
F17.18 Output terminal status at NO.5 fault
F17.19
NO.5 fault interval
F17.20
NO.4 fault type
F17.21
NO.4 fault interval
F17.22 NO.3 fault type
F17.23
NO.3 fault interval
F17.24
NO.2 fault type
F17.25 NO.2 fault interval
F17.26 NO.1 fault type
F17.27
NO.1 fault interval
F17.12 - F17.19 record status parameters of HD5L-PLUS at the last fault.
F17.20 - F17.27 record the type and interval per time of four faults before the latest. The unit of interval is
0.1 hour.
6.2.19 F18: PWM Parameters
Ref. Code Function Description Setting Range [Default]
F18.00
Carrier frequency
1 - 16kHz [Depend on HD5L-PLUS]
Defines the carrier frequency of PWM output wave.
Controller Power Setting Range Factory Setting
0.2 - 22kW 1 - 16kHz 8kHz
30 - 45kW 1 - 12kHz 6kHz
1234
• The carrier frequency will affect the operating noise of the motor. The higher the carrier frequency, the
lower the noise made by the motor. Please properly set the carrier frequency properly.
• When the carrier frequency > the default value, HD5L-PLUS should be derated by 5% for every 1kHz
increase.
F18.01
Carrier freqency auto adjust selection
0,1 [0]
0: Prohibited.
1: Allowed.
F18.02
PWM overmodulation enable
0,1 [1]
0: Disable.
1: Enable.
F18.03
PWM overmodulation mode
0,1 [0]
0: Two phase and three phase swtich.
1: Three phase.
