hpmont HD5L-PLUS Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 8 Troubleshooting and Maintenance
HD5L-PLUS Series User Manual V1.0 87
Chapter 8 Troubleshooting and Maintenance
8.1 Troubleshooting
8.1.1 Fault Phenomenon
If a fault occurs, the keypad will display the fault code
, ALM
indicator lights on. Meanwhile, faulty relay
acts, HD5L-PLUS stops output and the motor coasts to stop.
8.1.2 Troubleshooting
When fault alarm occurs, user should record the fault in detail and take proper action according to the
Table 8-1.
If technical help is needed, contact the suppliers or directly call Shenzhen Hpmont Technology Co., Ltd.
Table 8-1 Fault and counter-measures
Fault Fault Reasons Counter-measures
No display when power up
• Input grid voltage is too low or none
• The power supply of the drive board
is faulty
• The wiring of the control board, drive
board and keypad is disconnected
• The rectifier bridge is damaged
• The controller buffer resistance is
damaged
• The control board and keypad are
faulty
• Check the input power voltage
• Check the bus voltage
• Reconnect the keypad, or check
the wiring of the control board,
drive board, and keypad
• Contact factory for repair
Lu
DC bus undervoltage
• At the begining of power on and at
the end of power off
• Input voltage is too low
• Improper wiring leads to
undervoltage of hardware
• It is normal status of power on and
power off
• Check input power voltage
• Check wiring and wire HD5L-PLUS
properly
E01
Acc. overcurrent
• Improper connection between
controller and motor
• Improper motor parameters
• The rating of the used HD5L-PLUS is
too small
• Acc./Dec. time is too short
• Connect HD5L-PLUS and motor
properly
• Set correct motor parameters
• Select controller with higher rating
• Set proper Acc. time and Dec. time
E02
Dec. overcurrent
E03
Constant speed
overcurrent
E04
Acc. overvoltage
• Input voltage is too high
• Dec. time is too short
• Improper wiring leads to overvoltage
of hardware
• Check power input
• Set a proper value for Dec. time
• Check wiring and wire HD5L-PLUS
properly
E05
Dec. overvoltage
E06
Constant speed
overvoltage
E08
Power module fault
• Short circuit between phases output
or the ground
• Output current is too high
• Power module is damaged
• Check the connection and connect
the wire properly
• Check the connection and
mechanism
• Contact the supplier for repairing
8
