Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Operation Instructions
HD5L-PLUS Series User Manual V1.0 35
Chapter 5 Operation Instructions
• Only when the terminal cover of HD5L-PLUS has been fitted can you switch on AC power source. Do not remove
the cover after power is switched on.
• Ensure the motor and the mechnical device are in the use application before HD5L-PLUS starts.
• To change the MCB, correctly set the parameters before operating.
• Do not check or detect the signal during HD5L-PLUS running.
• Do not randomly change HD5L-PLUS parameter setting.
• Please thoroughly complete all control debugging and testing, make all adjustments and conduct a full safety
assessment before switching the run command source of HD5L-PLUS.
• Do not touch the energy-depletion braking resistor due to the high temperature.
5.1 Function Description
Note:
In the following chapters, the noun description related to the operation, control, operation and status of the
controller will be mentioned many times.
Please read this section. It will help you to correctly understand and use the functions to be discussed.
5.1.1 Operation Mode
The operation mode defines how HD5L-PLUS receives run commands (start or stop command) and
speed command. There are selectable through parameter F00.05.
Operation Mode Description
Keypad control
The run command is controlled by RUN, STOP, JOG keys of the keypad; And the run speed
is set by F00.07.
Terminal analog
control
The run command is controlled by UP and DN of the terminal; And the run speed is set by
AI terminals.
Terminal speed
control
The run command is controlled by UP and DN of the terminal; And the run speed is set by
MS1 - MS3 multi-step speed terminal combination.
Communication
speed control
The run command and the run multi-step speed are set by PC communication.
