hpmont HD5L-PLUS Series User Manual

Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd.
24 HD5L-PLUS Series User Manual V1.0
4.5.3 FD Description
Set FD
To change the FD coefficient, shift 6-digit FD switches. When the switch shifts to ON, it means “1”,
otherwise means “0”.
Convert the 6-digit binary number into decimal number. Multiple the decimal number by 2, the result
is FD coefficient, as shown in Figure 4-9.
The Max. value is “111111” which is 63 * 2 FD.
Figure 4-9 FD setting
FD Wiring
Figure 4-10 FD optocoupler input
Figure 4-11 Single ended optocoupler input
ON
000 000: 1 FD
ON
123123
ON
000 010: 2*2 FD
ON
123123
ON
010 000: 16*2 FD
ON
123123
FD high bit FD low bit FD high bit FD low bit FD high bit FD low bit
P
G
FD output
MCB FD input
+
24V
CO
M
PE
GND
A+
A-
GN
D
B+
B-
OUT
B
COM
OU
TA
R
R
R
R
R
eco
mm
ende
d r
esi
st
or R =2
K
PG
FD output
MCB FD input
+24V
COM
P
E
GND
A
GND
B
OUTB
COM
OUTA
R
R
R
R
Recommended resistor R =2K
