hpmont HD5L-PLUS Series User Manual

Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd.
20 HD5L-PLUS Series User Manual V1.0
Table 4-6 Control terminal
Terminal Description
+10V, GND Analog power supply
Analog input use +10V power supply, the Max. output current is 100mA
•
GND is isolated to COM
P24V, COM Digital power supply Digital input use +24V as supply, the Max. output current is 200mA
AI, GND Analog input
Input voltage: 0 - 10V, input impedance: 32kΩ
•
F13.00 set function
DI1 - DI10, COM Digital input
Programmable bipolar optional input signal
Input voltage: 0 - 30VDC, input impedance: 4.7kΩ
• F12.01 - F12.10 set function
Jumper J1 sets the input level
• Short connect J1 with pin1,2, low level is valid (default).
• Short connect J1 with pin2,3, high level is valid.
DO1 - DO2,
COM
Digital output
Programmable optical-coupled isolation, open collector output
Output voltage: 0 - 30VDC, the Max. output current is 50mA
•
F12.15 - F12.16 set function
Y1, CM1
Relay output
Programmable output
Contact rating: 250VAC/5A or 30VDC/5A
• F12.17 set function
Y2, CM2
Y3, CM3
Programmable output
Contact rating: 250VAC/3A or 30VDC/1A
•
F12.18 - F12.19 set function
RA, RB, RC
Programmable output
Contact rating: 250VAC/5A or 30VDC/5A
• RB, RC: Normally closed; RA, RC: Normally open
• F12.20 set function
MOD+, MOD-
Modbus
communication
485 communication terminal
USB USB interface
Connect MT70-BLE-A (bluetooth module), use Android phone to debug
HD5L-PLUS
• See section 5.3, on page 42
CN12, CN13 OTA download port
Optional HP-OTA-A, remote upgrade HD5L-PLUS software by computer
or Android phone
•
See section 7.5, on page 86
1
3
