hpmont HD5L-PLUS Series User Manual

Chapter 7 Elevator Application Guidance Shenzhen Hpmont Technology Co., Ltd.
84 HD5L-PLUS Series User Manual V1.0
Ref. Code Function Value Remark
F03.00 Acc. speed 0.700m/s
2
If the controller can not fast-track
speed command of the elevator
controller, increase the values of
F03.00 - F03.05
F03.01 Start Acc. jerk 0.350m/s
3
F03.02 End Acc. jerk 0.600m/s
3
F03.03 Dec. speed 0.700m/s
2
F03.04 Start Dec. jerk 0.600m/s
3
F03.05 End Dec. jerk 0.350m/s
3
F04.00 Setting curve 00000
Change according to the
characteristics of analog curve
F04.01 Line 1 min. setting 0.0%
F04.02
Corresponding value of line 1 min.
setting
0.0%
F04.03 Line 1 max. setting 100.0%
F04.04
Corresponding value of line 1 max.
setting
100.0%
F04.05 Line 2 min. setting 0.0%
F04.06
Corresponding value of line 2 min.
setting
0.0%
F04.07 Line 2 max. setting 100.0%
F04.08
Corresponding value of line 2 max.
setting
100.0%
F06.00 Pre-torque selection 1 Analog weighing feedback
F06.01 Up pre-torque bias 50.0%
Set according to actual situation
and debug according to running
effect
F06.02 Down pre-torque bias 50.0%
F06.03 Up electrical pre-torque gain 1.000
F06.04 Up brake pre-torque gain 1.000
F06.05 Down electrical pre-torque gain 1.000
F06.06 Down brake pre-torque gain 1.000
F12.01 DI1 function 1 Controller enabled (EN)
F12.02 DI2 function 2 UP
F12.03 DI3 function 3 DN
F12.15 DO1 function 2 Controller is in running
F12.16 DO2 function 3 Controller is at zero-speed running
F12.20 Y4 (RLY ) output function 14 Controller fault
F13.00 AI function 1 Speed setting
F13.04 AI bias 0.0%
Adjust according to actual situation F13.05 AI gain 1.00
F13.06 AI filter time 0.05s
