80
INTELLIGENT ACTUATOR
Part 1 Installation
3.5
Connection Cables for Multi-point IO Board
Model: CB-X-PIOH020
Socket: HIF6-100D-1.27R (Hirose)
Flat cable (50 cores) UL2651 AWG28x2
Cable 1 (pins 1 to 50)
Open end without
connector
Cable 2 (pins 51 to 100)
109
111
