INTELLIGENT ACTUATOR
Appendix
1. I/O Parameters
No. Parameter name
Default value
(Reference)
Input
range
Unit Remarks
1 I/O port assignment type 1 0 to 20 0: Fixed assignment
1: Automatic assignment (Priority: Network I/F module  Slot 1
(standard I/O) ~; * Ports are assigned only for the installed
adjoining slots, starting from slot 1 = For safety reasons)
2 Input port start number
with fixed standard I/O
assignments (I/O1)
000 -1 to 599 0 + (Multiple of 8) (Invalid if a negative value is set)
3 Output port start number
with fixed standard I/O
assignments (I/O1)
300 -1 to 599 300 + (Multiple of 8) (Invalid if a negative value is set)
4 Input port start number
with fixed expanded I/O1
assignments (I/O2)
-1 -1 to 599 0 + (Multiple of 8) (Invalid if a negative value is set) (Slot next to
the standard I/O slot)
5 Output port start number
with fixed expanded I/O1
assignments (I/O2)
-1 -1 to 599 300 + (Multiple of 8) (Invalid if a negative value is set)
6 Input port start number
with fixed expanded I/O2
assignments (I/O3)
-1 -1 to 599 0 + (Multiple of 8) (Invalid if a negative value is set)
7 Output port start number
with fixed expanded I/O2
assignments (I/O3)
-1 -1 to 599 300 + (Multiple of 8) (Invalid if a negative value is set)
8 Input port start number
with fixed expanded I/O3
assignments (I/O4)
-1 -1 to 599 0 + (Multiple of 8) (Invalid if a negative value is set)
9 Output port start number
with fixed expanded I/O3
assignments (I/O4)
-1 -1 to 599 300 + (Multiple of 8) (Invalid if a negative value is set)
10 Standard I/O error monitor
(I/O1)
1 0 to 5 0: Do not monitor
1: Monitor
2: Monitor (Do not monitor errors relating to 24-V I/O power
source)
3: Monitor (Monitor only errors relating to 24-V I/O power source)
* Some exceptions apply.
11 Expanded I/O1 error
monitor (I/O2)
1 0 to 5 0: Do not monitor
1: Monitor
2: Monitor (Do not monitor errors relating to 24-V I/O power
source)
3: Monitor (Monitor only errors relating to 24-V I/O power source)
* Some exceptions apply.
(Slot next to the standard I/O slot)
* If 0 (= Do not monitor) or 2 (= Monitor (Monitor only errors
relating to 24-V I/O power source)) is selected, a system error
will not generate even when an abnormality relating to the 24-V
I/O power source occurs. However, all subsequent actual
outputs from the digital I/O board will be cut off by a circuit to
protect the controller.
12 Expanded I/O2 error
monitor (I/O3)
1 0 to 5 0: Do not monitor
1: Monitor
2: Monitor (Do not monitor errors relating to 24-V I/O power
source)
3: Monitor (Monitor only errors relating to 24-V I/O power source)
* Some exceptions apply.
* If 0 (= Do not monitor) or 2 (= Monitor (Monitor only errors
relating to 24-V I/O power source)) is selected, a system error
will not generate even when an abnormality relating to the 24-V
I/O power source occurs. However, all subsequent actual
outputs from the digital I/O board will be cut off by a circuit to
protect the controller.
