Appendix
No. Parameter name
Default value
(Reference)
Input
range
Unit Remarks
13 Expanded I/O3 error
monitor (I/O4)
1 0 to 5 0: Do not monitor
1: Monitor
2: Monitor (Do not monitor errors relating to 24-V I/O power
source)
3: Monitor (Monitor only errors relating to 24-V I/O power source)
* Some exceptions apply.
* If 0 (= Do not monitor) or 2 (= Monitor (Monitor only errors
relating to 24-V I/O power source)) is selected, a system error
will not generate even when an abnormality relating to the 24-V
I/O power source occurs. However, all subsequent actual
outputs from the digital I/O board will be cut off by a circuit to
protect the controller.
14 Number of network I/F
module remote input ports
used
0 0 to 256 Multiple of 8
15 Number of network I/F
module remote output
ports used
0 0 to 256 Multiple of 8
16 Starting input port number
based on fixed network
I/F module assignments
-1 -1 to 599 0 + (Multiple of 8) (Invalid if a negative value is set)
17 Starting output port
number based on fixed
network I/F module
assignments
-1 -1 to 599 300 + (Multiple of 8) (Invalid if a negative value is set)
18 Network I/F module error
monitor
1 0 to 5 0: Do not monitor
1: Monitor
* Some exceptions apply.
19 (For expansion) 0
20 Input filtering periods 2 1 to 9 msec Input signal is recognized when the status is held for twice the
period set by this parameter.
21 For future expansion
(change prohibited)
0 1 to 9
22 Remote-I/O-card fieldbus
ready timeout value
2000 0 to
99999
msec Timeout check is not performed if “0” is set.
23 Overcurrent/power-supply
error detection input
specification for multi-
point DIO external
terminal block
0H 0H to
FFFFFFF
FH
Bits 0 to 3: Standard I/O (I/O1) input specification
Bits 4 to 7: Expanded I/O1 (I/O2) input specification
Bits 8 to 11: Expanded I/O2 (I/O3) input specification
Bits 12 to 15: Expanded I/O3 (I/O4) input specification
(0: Do not use error detection input
1: Use error detection input = IN023 on card
2: Use error detection input = IN047 on card
3: Use error detection input = IN023/47 on card)
* Determine an appropriate setting after checking the specification of the
multi-point DIO terminal block unit to be connected.
* The input port used for the error detection input cannot be used as a
general-purpose input port.
24 I/O setting bit pattern 1
(global specification)
10000H 0H to
FFFFFFF
FH
Bits 0 to 3: RDY OUT function selection (System IO)
(0: SYSRDY (Software = PIO trigger program can be
run) and hardware is normal (emergency stop has not
been actuated and hardware error is not present)
1: Error of operation-cancellation level or higher is not
present
2: Error of cold-start level or higher is not present)
Bits 4 to 7: RDY LED function selection
(0: Program can be run
1: Error of operation-cancellation level or higher is not
present
2: Error of cold-start level or higher is not present)
Bits 8 to 11: DET (MELT) (drive-source cutoff relay fused) signal
enable/disable selection
(0: Disable, 1: Enable)
Bits 12 to 15: Drive-source cutoff relay DET (MELT) error level (when
voltage drop cannot be checked)
(0: Cold start, 1: Message)
Bits 16 to 19: Drive-source cutoff relay DET (MELT) error level (when
voltage drop is checked)
(0: Cold start, 1: Message)
