IAI X-SEL User Manual

45
INTELLIGENT ACTUATOR
Part 1 Installation
4.2 P/Q Type (Standard Specification) 6-axis Controller (Three-phase Standard Specification,
Single-phase Global Specification, Single-phase Standard Specification)
External views of enclosures for various 6-axis controllers are shown below (the external enclosure
dimensions are the same for 5-axis and 6-axis controllers).
Fig. 4-5 P/Q Type 4-axis Controller (Incremental Specification) (Three-phase Standard Specification, Single-
phase Global Specification, Single-phase Standard Specification)
Fig. 4-6 P/Q Type 6-axis Controller with Absolute Brake Unit (Three-phase Standard Specification, Single-phase
Global Specification, Single-phase Standard Specification)
