IAI X-SEL

379
INTELLIGENT ACTUATOR
Appendix
 Expansion I/O Board (Optional)
Type: IA-103-X-32 Type: IA-103-X-16
Pin No. Category Port No. Function Pin No. Port No. Function
1 -
+24-V input
1 -
+24-V input
2 32 General-purpose input 2 32 General-purpose input
3 33 General-purpose input 3 33 General-purpose input
4 34 General-purpose input 4 34 General-purpose input
5 35 General-purpose input 5 35 General-purpose input
6 36 General-purpose input 6 36 General-purpose input
7 37 General-purpose input 7 37 General-purpose input
8 38 General-purpose input 8 38 General-purpose input
9 39 General-purpose input 9 39 General-purpose input
10 40 General-purpose input 10 40 General-purpose input
11 41 General-purpose input 11 41 General-purpose input
12 42 General-purpose input 12 42 General-purpose input
13 43 General-purpose input 13 43 General-purpose input
14 44 General-purpose input 14 44 General-purpose input
15 45 General-purpose input 15 45 General-purpose input
16 46 General-purpose input 16 46 General-purpose input
17 47 General-purpose input 17
Input
47 General-purpose input
18 48 General-purpose input 18 316 General-purpose output
19 49 General-purpose input 19 317 General-purpose output
20 50 General-purpose input 20 318 General-purpose output
21 51 General-purpose input 21 319 General-purpose output
22 52 General-purpose input 22 320 General-purpose output
23 53 General-purpose input 23 321 General-purpose output
24 54 General-purpose input 24 322 General-purpose output
25 55 General-purpose input 25 323 General-purpose output
26 56 General-purpose input 26 324 General-purpose output
27 57 General-purpose input 27 325 General-purpose output
28 58 General-purpose input 28 326 General-purpose output
29 59 General-purpose input 29 327 General-purpose output
30 60 General-purpose input 30 328 General-purpose output
31 61 General-purpose input 31 329 General-purpose output
32 62 General-purpose input 32 330 General-purpose output
33
Input
63 General-purpose input 33 331 General-purpose output
34 316 General-purpose output 34 332 General-purpose output
35 317 General-purpose output 35 333 General-purpose output
36 318 General-purpose output 36 334 General-purpose output
37 319 General-purpose output 37 335 General-purpose output
38 320 General-purpose output 38 336 General-purpose output
39 321 General-purpose output 39 337 General-purpose output
40 322 General-purpose output 40 338 General-purpose output
41 323 General-purpose output 41 339 General-purpose output
42 324 General-purpose output 42 340 General-purpose output
43 325 General-purpose output 43 341 General-purpose output
44 326 General-purpose output 44 342 General-purpose output
45 327 General-purpose output 45 343 General-purpose output
46 328 General-purpose output 46 344 General-purpose output
47 329 General-purpose output 47 345 General-purpose output
48 330 General-purpose output 48 346 General-purpose output
49 331 General-purpose output 49 347 General-purpose output
50
Output
-
0 V
50
Output
-
0 V
Note) Port numbers indicate ports on an I/O1 (I/O2) expansion board.
