IAI X-SEL User Manual

49
INTELLIGENT ACTUATOR
Part 1 Installation
4.4 Q Type (Three-phase Global Specification) 6-axis Controller
External views of enclosures for various 6-axis controllers are shown below (the external enclosure
dimensions are the same for 5-axis and 6-axis controllers).
Fig. 4-13 Q Type 6-axis Controller (Incremental Specification) (Three-phase Global Specification)
Fig. 4-14 Q Type 6-axis Controller with Absolute Brake Unit (Three-phase Global Specification)
