INTELLIGENT ACTUATOR
Appendix
4.
How to Use T
AG and GOTO
Description
Use GOTO and TAG com
mands to repeat the same operati
on within the pro
gram or to jump to a desired
step if a condition is satisfied. A TAG command
can be written in a step either before or after a
GOTO
command.
Example of Use 1
Repeat the same operation.
Example of Use 2
Skip steps.
Repeated.
Steps to be repeated
Jump.
Steps to be ignored
379
381
