47
INTELLIGENT ACTUATOR
Part 1 Installation
4.3 Q Type (Three-phase Global Specification) 4-axis Controller
External views of enclosures for various 4-axis controllers are shown below (the external enclosure
dimensions are the same for 1-axis to 4-axis controllers).
Fig. 4-9 Q Type 4-axis Controller (Incremental Specification) (Three-phase Global Specification)
Fig. 4-10 Q Type 4-axis Controller with Absolute Brake Unit (Three-phase Global Specification)
