IAI X-SEL

44
INTELLIGENT ACTUATOR
Part 1 Installation
Fig. 4-3 P/Q Type 4-axis Controller with Expansion I/O Board (Incremental Specification) (Three-phase Standard
Specification, Single-phase Global Specification, Single-phase Standard Specification)
Fig. 4-4 P/Q Type 4-axis Controller with Expansion I/O Board + Absolute Brake Unit (Three-phase Standard
Specification, Single-phase Global Specification, Single-phase Standard Specification)
