Chapter 8. Advanced host and volume administration 381

6. Click Map Volumes. A confirmation window is presented, as shown in Figure 8-9.

Figure 8-9 Volume mapping confirmation window

8.1.2 Unmapping volumes from a host

To unmap a volume from a host, follow the steps listed here:

1. From the main navigation pane, Click Hosts as shown in Figure 8-10.

Figure 8-10 Hosts
