544 Implementing the IBM Storwize V5000 Gen2 with IBM Spectrum Virtualize V8.1
10.4.12 Renaming Consistency Group
To rename a Consistency Group, complete the following steps:
1. From the main panel, click Copy Services → Consistency Groups.
2. From the left pane, select the Consistency Group that you want to rename. Then, select
Actions → Rename, as shown in Figure 10-62.
Figure 10-62 Renaming a Consistency Group
3. Enter the new name that you want to assign to the Consistency Group and click Rename,
as shown in Figure 10-63.
Figure 10-63 Changing the name for a Consistency Group
The new Consistency Group name is displayed in the Consistency Group pane.
10.4.13 Deleting FlashCopy mapping
Complete the following steps to delete a FlashCopy mapping:
1. From the main panel, click Copy Services → FlashCopy or Consistency Groups, or
FlashCopy Mappings.
2. In the table, select the FlashCopy mapping that you want to delete.
3. Click Actions → Delete Mapping, as shown in Figure 10-64 on page 545.
Consistency Group name: The name can consist of the letters A - Z and a - z, the
numbers 0 - 9, the dash (-), and the underscore (_) character. The name can be 1 - 63
characters. However, the name cannot start with a number, a dash, or an underscore.
Selecting multiple FlashCopy mappings: To select multiple FlashCopy mappings,
hold down Ctrl and click the other entries that you want to delete. This capability is only
available in the Consistency Groups pane and the FlashCopy Mappings pane.
Tip: You can also right-click a FlashCopy mapping and select Delete Mapping.
