SET MODE
Selects the switching relay type for [RELAY] from
Lead and MOS-FET.
Select the suitable relay type when connecting a non-
Icom linear amplifier.
•Lead :Usemechanicalrelay.
(16VDC/0.5Amax.;default)
•MOS-FET:Usesemiconductortyperelay.(250
V/200mAmax.)
Selects the desired band for the operating frequency
band control signal output from [ACC2–B] (pin 4).
•MAIN :Outputsthebandsignaldisplayedinmain
readout.
•SUB :Outputsthebandsignaldisplayedinsub
readout.
•TX  :Outputsthebandsignal,thatcanbetrans-
mitted. (default)
Selects the desired band for the operating frequency
band control signal output from [ACC2–A] (pin 4).
•MAIN :Outputsthebandsignaldisplayedinmain
readout.
•SUB :Outputsthebandsignaldisplayedinsub
readout.
•TX  :Outputsthebandsignal,thatcanbetrans-
mitted. (default)
■ ACC set mode (continued)
Selects the desired item for an external meter indica-
tion (main readout).
•Auto :Outputs the receiving signal strength
level during receive, and outputs the se-
lected level (selected with [METER]), dur-
ing transmit. (default)
•S(MAIN):Outputsthereceivingsignalstrengthlevel
during receive.
•Po :Outputsthetransmittingpowerleveldur-
ing transmit.
•SWR :OutputstheVSWRlevelduringtransmit.
•ALC :OutputstheALClevelduringtransmit.
•COMP :Outputs the compression level during
transmit.
•Vd : Outputs the drain terminal voltage of the
final amplifier MOS-FETs.
•Id : Outputs the drain current of the final am-
plifier MOS-FETs.
