Auto Sentry® flex User Manual 25 Introduction
Figure 3. Custom Touch Screen Example
Single Board Computer
The Single Board Computer, often called the motherboard enclosure, provides processing and
memory for the Auto Sentry® flex. Different peripheral devices (for example: bill dispenser, bill
acceptor, and others) connect to the WashConnect through various communication ports (COM1,
COM2, COM3, COM4, and 4 USB, etc.).
Figure 4. SBC (Single Board Computer)
