Auto Sentry® flex User Manual 94 Service Unit Screen
5 Click the Save button.
The user’s password and PIN are saved.
Accessing the Service Unit Screen
To access the Service Unit Screen for the Auto Sentry® flex®, first locate one of the service buttons
inside the Auto Sentry® flex, in either the upper-left chamber of the Auto Sentry or in the lower-
right chamber.
Figure 71. Service Buttons
To log on to the Auto Sentry® flex service unit screen, follow these steps:
1 Unlock the Auto Sentry® flex door.
2 Open the door with a hex key, and then locate the service button.
See Figure71.
3 Press and hold one of the Service buttons for a few seconds, and then release.
The Service Unit screen appears on the Auto Sentry touch screen.
NOTE: If the service button is held too long, then it will reboot the unit if the Switch Enabled
setting is set to TRUE.
SERVICE BUTTON
UPPER-LEFT CHAMBER
SERVICE BUTTON
LOWER CHAMBER
ON THE BACK SIDE OF
THE AUTO SENTRY
WHERE THE BILL
DISPENSER IS LOCATED
