Auto Sentry® flex User Manual 46 Operating

Figure 30. Example Custom Video

About Product Information Clips

You can include short informational clips at the Auto Sentry® flex. Informational clips typically

feature products such as tire shine and sealer wax.

Figure 31. Promotional Video Clips

 Customers view promotional video clips by tapping the Info button next to the extra service

featuring the product.

NOTE: The following clips are available: Rain-X

, tire shine, polish wax, sealer wax and under

carriage. These short promotional clips are provided at no charge. Contact ICS technical

support for more information.
