Table of Contents
1. Scope of Delivery 23
2. Important Safety Instructions 24
3. Intended
Use 25
4. Device Description 25
4.1. Connections, Operating and
Display Elements 26
4.2. Technical Data 27
5. Initial Start-up 28
6. Operating States and
Operation 29
6.1. Operating Concept 29
6.2. Operating States 30
6.3. Alarm and Errors 31
6.3.1. Alarm 31
6.3.2. Errors 32
6.4. Starter Battery 32
7. Further Information
for Skilled Electricians 33
7.1. Personal Protection 33
7.1.1. Insulation 33
7.1.2. Charge Mode 33
7.1.3. Discharge Mode 34
7.1.4. Connecting more than
one Consumer to
the Instagrid ONE 34
7.2. Protective Measures
at the Output 34
7.2.1. Overload 34
7.2.2.Further
Protective Functions 35
7.3. Protective Measures at the
Input 35
8. Service and Maintenance 35
8.1. Replacing the Melting Fuse
of the Charging Input 35
8.2. Cleaning and Maintenance 36
8.3. Replacing the Frame 36
9. Miscellaneous 36
9.1. Storage 36
9.2. Transport and Shipping 37
10. Symbols 37
11. Manufacturer’s Declarations 38
11.1. Declaration of Conformity 38
11.2. WEEE Declaration /
Disposal 38
11.3. Output and Service Life
Parameters (EU
Regulation 2023/1542 on
Batteries and Waste Batteries) 38
11.4. Licences and Copyrights 39
12. Contact 39
