4.2. Technical Data
Operating state: Discharging
Output voltage 230 VAC / 50 Hz
Nominal output 3,600 W / 16 A
150% overload (5,400 W / 24 A) Operation possible for <500 s
200% overload (7,200 W / 32 A) Operation possible for <50 s
250% overload (9,000 W / 40 A) Operation possible for <10 s
Peak output 18,000 W / 80 A
Maximum operating time (idling) 150 h
Line protection 16 A - analogue circuit breaker “B16”
Permissible ambient temperature - 20°C to 60°C
Operating state: Charging
Input voltage 120-240 VAC / 50-60 Hz
Nominal output 500-1,000 W / 4 A
Power consumption at fully
completed charging operation
<0.5 W
Charging time <3 h to 100%
Permissible ambient temperature 0 °C to 45 °C
General
Capacity 2,100 Wh
Weight 20 kg
Dimensions 420 x 210 x 420 mm
Type of protection IP54
Protection class Class II / double insulated
Noise emission <10 dB(A)
Bluetooth frequency range (IOT module) 2400 MHz to 2483.5 MHz
Bluetooth transmission power (IOT module) 2.2 dBm
Storage > 3 years
Connections
Output socket CEE 7/3 socket (16 A)
Output socket Neutrik powerCON® TRUE1® TOP
AC charging input Neutrik powerCON® TRUE1® TOP
Melting fuse of the charging input T5A L 250V
