SYSTEM BUS DESIGN
8.3.2 An Example EISA Chip Set
Figure 8-1 shows a high-performance system with an Intel486 processor residing on the host bus.
Three EISA support devices, an EISA bus controller (EBC), an integrated system peripheral
(ISP), and EISA bus buffers (EBB), interface the host bus to the EISA bus. The three devices also
communicate with each other.
