Neither the USB stick, nor the User SD card will be deleted or formatted by the flight system.
One log directory always contains four files:
 ASCHP.LOG
 ASCTEC.IFO
 ASCTEC.LOG
 FLIGHT.KML.
These files cannot be accessed directly, but by using AscTec Navigator, it is possible to get a
map view of the flight, or export a flight track as KML or GPX.
In AscTec Navigator, the Flightbook gives a chronological overview of all flights stored on an SD
card or USB stick
Note: Regularly make backup copies of storage devices and reformat the devices
afterwards. Especially when working on complex projects, during which the logs
are needed for geo-referencing; it is helpful to start with clean storage media.
Note: The Intel
®
Falcon™ 8+ can fly without any active logging device. It is the responsibility
of the operator to make sure that all flights are properly logged if it is a legal
requirement in the country where the system is used.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
