Intel FALCON 8+ Flight Manual

DESCRIPTION
© 2017 Intel Corporation. All rights reserved. 77
REV 00
APR 2017
Without headphones connected, acoustic warnings are played back through a small
loudspeaker inside the Intel
®
Cockpit GCS.
7.2.2 Overview of the Status Display Controls
The Status Display shows all relevant information for flying. It is built into the Intel
®
Cockpit GCS
control unit.
The Status Display shows the current settings and allows the operator to adjust specific
functions of the Intel
®
Falcon™ 8+ UAS by using the four buttons under the lower left corner of
the Status Display.
Escape (ESC) (left side) is used to leave menus / submenus and to clear functions.
The arrow LEFT button (middle, left side) and the arrow RIGHT button (middle, right
side) are used to scroll through menus or alter parameters.
Enter (ENT) (right side) is used to enter menus and activate functions
WARNING: RISK OF PERMANENT HEARING LOSS FROM USING EARPHONES OR
HEADPHONES WITH THIS PRODUCT AT HIGH VOLUME.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
