Intel FALCON 8+ Flight Manual

MAINTENANCE MANUAL
INTEL
®
FALCON™ 8+ UAS
WEIGHT / BALANCE / EQUIP
56 © 2017 Intel Corporation. All rights reserved.
REV 00
APR 2017
SECTION 6 WEIGHT AND BALANCE/EQUIPMENT LIST
INTRODUCTION
The Intel
®
Falcon™ 8+ UAS is equipped with one payload bay. The aircraft may be operated
without a payload or with an approved camera and gimbal mount.
AIRCRAFT WEIGHING PROCEDURES
The Intel Falcon 8+ UA is designed to remain within manufacturers’ weigh and balance limits
when using all authorized and approved payloads and components. Any alterations or
substitutions are strictly prohibited and may void the warranty.
WEIGHT AND BALANCE
The Remote Pilot should only reweigh the aircraft if they are concerned the Center of Gravity
has been altered and the UAS does not meet a condition for safe flight.
COMPREHENSIVE EQUIPMENT LIST
WARNING: TO AVOID COMPONENT MALFUNCTION, SERIOUS INJURY, AND PROPERTY
DAMAGE, ONLY USE GENUINE INTEL
®
FALCON™ 8+ PARTS OR PARTS CERTIFIED BY
MANUFACTURER.
CAUTION: UNAUTHORIZED PARTS MAY CAUSE SYSTEM MALFUNCTIONS AND COMPROMISE
SAFETY.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
