Intel FALCON 8+ Flight Manual

SUPPLEMENTS
© 2017 Intel Corporation. All rights reserved. 133
REV 00
APR 2017
SECTION 7- AIRCRAFT AND SYSTEMS DESCRIPTION
The Independent Camera Control (ICC) allows a camera operator to control the main camera
functions from a gamepad, which is connected to the Intel
®
Cockpit GCS via a port located on
the back of the Intel
®
Cockpit GCS.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
