The following table presents an overview of the function assignment:
CAMERA
SONY ALPHA 7R
INSPECTION-PAYLOAD ZS50
BUTTON ON
ICC
(1)
Start/Stop video
/
(2)
Trigger photo
Trigger photo (both cameras)
(3)
View last image
/
(4)
/
Change color palette (when FLIR is
active)
(5)
Camera tilt (up/down)
Yaw (left/right)
Camera tilt (up/down)
Yaw (left/right)
(6)
Camera tilt (up/down)
Yaw (left /right)
Camera tilt (up/down)
Yaw (left/right)
(7)
Horizontal tilt (adjust camera
horizon) (left/right)
Exposure compensation +/-
(up/down)
Horizontal tilt (adjust camera
horizon) (left/right)
Switch camera (up/down)
(8)
Shutter speed -
Zoom - (when ZS50 is active)
(9)
Shutter speed +
Zoom + (when ZS50 is active)
(10)
Camera tilt velocity -
Camera tilt velocity -
(11)
Camera tilt velocity +
Camera tilt velocity +
SECTION 8- HANDLING, SERVICING AND MAINTENANCE
There is no change to the aircraft handling, servicing and maintenance when the Independent
Camera Control (ICC) is used.
SECTION 10- SAFETY
There is no change to the aircraft safety when the Independent Camera Control (ICC) is used.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
