GROUND HANDLING
This section provides details to the Remote Pilot on how to do all of the following:
8.9.1 Transport
The transport set consists of different
cases with precision water jet cut inlays
designed for the Intel
®
Falcon™ 8+ UAS
with all its accessories. For easy
transportation, the Intel
®
Falcon™ 8+
UAS case has a retractable handle and
wheels.
The Intel transport cases are water
resistant, crush-proof and dust proof.
The Intel Backpack is not safe for air
freighting, but very useful for missions
in remote areas, since it is light and
relatively compact.
Use reasonable care when transporting
components to prevent damage.
For transporting and storing the Intel
®
Powerpack™ Batteries, use only LIPO-SAFE cases.
CAUTION: THE INTEL® FALCON™ 8+ UAS AND INTEL® COCKPIT GCS SHOULD BE
TRANSPORTED FULLY ASSEMBLED.
CAUTION: WHEN SHIPPING THE INTEL® FALCON™ 8+ UAS IN THE TRANSPORT CASE WITH A
MOUNTED PAYLOAD, THE FOAM INLET OF THE PAYLOAD CASE MUST BE USED TO
AVOID DAMAGES DURING TRANSPORT.
CAUTION: THE INTEL TRANSPORT CASES ARE NOT LIPO SAFE CASES AND THEREFORE NOT
SUFFICIENT FOR SHIPPING INTEL® POWERPACK™ BATTERIES.

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
